Designed for industrial use, this controller offers fast processing speeds, expandable I/O capacity, built-in high-speed motion control, and serial communication ports, making it ideal for machine automation and process control applications.

Key Features

• Total I/O: 32 points (16 digital inputs DC24V, 16 transistor outputs DC5-30V sink type)

• Program memory: 64k steps built-in RAM (expandable to 256k steps with optional cassette)

• Processing speed: 0.065 µs per basic instruction for fast cycle times

• Expansion capability: Supports up to 384 total I/O points (main + expansion + remote I/O via fieldbus)

• Built-in motion control: 4-axis pulse output (max 100kHz) + 6 high-speed counters (max 100kHz)

• Communication ports: RS-232 (programming) + RS-485 (Modbus/serial)

• Certifications: CE, UL, cUL, CSA compliant for global industrial use

• Operating range: Temperature 0–55°C, humidity 5–95% RH (non-condensing)
